AT-1060C Digital Counting Screw Feeder
Text block
SKU AT-1060C
by Hakko
Original price
$1,536.97
-
Original price
$1,536.97
Original price
$1,536.97
$1,536.97
$1,536.97
-
$1,536.97
Current price
$1,536.97
Pay with a Purchase Order
As part of our payment options, we gladly accept purchase orders. However, it is important to note that setting up terms with Starboard Technologies is necessary. To request the required information, please email us at rubin@starboardtech.com or make use of our user-friendly online submission form.
FEEDER,SCREW,M1.0-6.0,w/DIGITAL COUNTER
Specifications
| Model Name | AT-1060C |
| Part No. | AT-1060C |
| Output Speed | 2pcs/second |
| Protection/Recovery Function | Overload protection circuit, reversepower polarity prevention circuit |
| AC Adapter | Input:100 - 240VAC, 50/60HzOutput: 12VDC |
| Dimension | 235 (L) x 165 (W) x 180 (H) mm |
| Weight | 4.8kg (10.6lbs) |
| Screw Diameter | M1 - M6 (#000 - #12) |
| Max Screw Head Diameter | 12 mm |
| Maximum Screw Length | 25mm |
| Minimum Screw Length | Single screw: diameter x1.0Screw with spring washer: diameter + (0.5x diameter)Screw with spring and flat washers: diameter + (1.1x diameter) |
| Screw Material | Ferromagnetic |
